| Power | - DC Input: 12 VDC 1.5A
- PoE: Compatible with 802.3af/at
|
| Physical Size | - 20.3 cm / 7.99 In. (L), 20.3 cm / 7.99 In. (W), 5cm/1.97In. (H)
|
| Weight | |
| RF | - Adaptive antenna array that provides 3,000+ unique antenna patterns
- Physical antenna gain: 3dBi (2.4 and 5GHz)
- BeamFlex+ SINR Tx gain*: up to 6dB
- BeamFlex+ SINR Rx gain*: up to 4dB
- Interference mitigation: up to 15 dB
- Minimum Rx sensitivity†: -101 dBm
|
| Ethernet Ports | - 2 ports, auto MDX, auto-sensing 10/100/1000 Mbps, RJ-45
- Power over Ethernet (802.3af/at) with Category 5/5e/6 cable
|
| Environmental Conditions | - Operating Temperature: 32°F (0°C) - 122°F (50°C)
- Operating Humidity: up to 95% non-condensing
|
| Power Consumption | - 5W (minimum)
- 7W (typical)
- 13W (peak)
|
| Performance and Capacity |
| PHY Data Rates | |
| Concurrent Stations | |
| Simultaneous VoIP Clients | - Up to 60 (802.11e/WMM support), 30 per radio
|
| Network Architechture |
| IP | |
| VLANs | - 802.1Q (1 per BSSID or dynamic, per user based on RADIUS)
- Port-based
|
| 802.1x for Wired Ports | |
| Tunneling | |
| Multimedia and Quality of Service |
| 802.11e/WMM | |
| Software Queues | - Per WLAN priority (2), Per traffic type (4), per client
|
| Traffic Classification | - Automatic, heuristics and TOS based or VLAN-defined
|
| Rate Limiting | - Dynamic per-user or per-WLAN
|
| Management |
| Deployment Options | - Standalone (individually managed)
- Managed by ZoneDirector
- Managed by FlexMaster
|
| Configuration | - Web User Interface (HTTP/S)
- CLI (Telnet/SSH), SNMP v1, 2, 3
- TR-069 vis FlexMaster
|
| Auto Software Updates | - FTP or TFTP, remote auto available
|
| Wi-Fi |
| Standards | - IEEE 802.11a/b/g/n
- 2.4GHz and 5GHz concurrent operation
|
| Supported Data Rates | - 802.11n: 6.5 Mbps – 216.7 Mbps (20MHz) 13.5 Mbps – 450 Mbps (40MHz)
- 802.11a: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
- 802.11b: 11, 5.5, 2 and 1 Mbps
- 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
|
| Radio Chains / Streams | |
| RF Power Output†† | - Max Transmit Power(1) 28 dBm on 2.4 GHz; 26 dBM on 5 GHz
|
| Channelization | |
| Frequency Band | - IEEE 802.11n: 2.4 – 2.484 GHz and 5.15 – 5.85 GHz
- IEEE 802.11a: 5.15 – 5.85 GHz
- IEEE 802.11b: 2.4 – 2.484 GHz
|
| Operating Channels | - US/Canada: 1-11, Europe (ETSI X30): 1-13, Japan X41: 1-13
- 5 GHz channels: Country dependent
|
| BSSID | - Up to 32 per radio (64 total)
|
| Power Save | |
| Wireless Security | - WEP, WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
- Authentication via 802.1X, local authentication database, support for RADIUS, LDAP, and ActiveDirectory
|
| Certifications††† | - U.S., Europe, Canada
- WEEE/RoHS compliance
- EN 60601-1-2
- Wi-Fi Alliance certified
- UL 2043 plenum rated
|
| Subway and Railroad Certifications | - EN50121-1 EMC
- EN50121-4 Immunity
- IEC 61373 Shock & Vibration
|
